Communication Options
DBC Import Function
Supports importing any CAN DBC file
Instantly compatible with major ECU systems (Syvecs, MoTeC, Pectel, Link, etc.)
OBD-II Functionality
Read & clear DTCs (Diagnostic Trouble Codes) from any OBD-II–equipped vehicle
Real-time data monitoring via standard OBD-II PIDs up to 200hz update rate depending on car CAN type.
Car Selection Presets
Preloaded configurations for vehicles (e.g., Nissan R35)
Simplifies CAN bus mapping for commonly used models
CAN TX Options
Transmit custom messages or “modes” back to the ECU
Flexibility to emulate sensors or inject control commands
Extensive CAN integration
Enables wireless pairing with:
Smartphones & tablets (iOS & Android)
In-dash head units (via BLE-capable interfaces)
Syvecs Dash Mobile Application
Download the Apps here:
https://play.google.com/store/apps/details?id=com.twisted_solutions_limited.Syvecs_Dash
https://apps.apple.com/gb/app/syvecs-dash/id6744581329
Customizable Dash Layouts
Multiple dashboard templates, all fully configurable
Any data point can be displayed (e.g., RPM, temperatures, pressures, GPS speed)
Warning & Alert System
Define thresholds on any CAN or internal sensor value
Receive visual/audible alerts when limits are exceeded (e.g., oil pressure low, over-rev)
Performance Measurement
If a Syvecs 100hz GPS Module is already fitted with a Syvecs ECU then the following is possible, if not a Syvecs GPSBT is needed for below
Calculate 0–100 km/h, 100–200 km/h, ¼ mile times in real time
Drag Tree option to see reaction times also
Store best-run, quickest segment, and lap data
Track Mapping & Lap Timing
If a Syvecs 100hz GPS Module is already fitted with a Syvecs ECU then the following is possible, if not a Syvecs GPSBT is needed for below
GPS-based auto‐track detection: draws the circuit as you drive
Automatic sector creation and timing: see best lap, sector times, etc.
Ideal for racers who want immediate feedback without manual track setup
